ARC20
ARC20
ARC20
Hydraulic Groups
Horizontal Hydraulic Groups for Wall Hung Boilers
Horizontal Hydraulic Groups for Wall Hung Boilers
Pressure CH
Pressure CH
3 bar to 3 bar
3 bar to 3 bar
Pressure DHW
Pressure DHW
0,2 bar to 6 bar
0,2 bar to 6 bar
Flow Rate DHW
Flow Rate DHW
2-20 l/min
2-20 l/min
Pressure Relief Valve
Pressure Relief Valve
Composite 3 Bar
Composite 3 Bar
Flow Restrictor
Flow Restrictor
10 l/min
10 l/min
/
/
*6 to 20 l/min
*6 to 20 l/min
*6 to 20 l/min
Filling System
Filling System
Manuel Tap 37mm
Manuel Tap 37mm
/
/
*37 - 63mm
*37 - 63mm
*37 - 63mm
Automatic Bypass
Automatic Bypass
Through PHE (380±30 mBar)
Through PHE (380±30 mBar)
Flow Detection
Flow Detection
Hall Effect Sensor
Hall Effect Sensor
Electric Connections
Electric Connections
Rast 2,5
Rast 2,5
Three Way Valve
Three Way Valve
ON-OFF Motor
ON-OFF Motor
NTC Port
NTC Port
G1/8"
G1/8"
Manometer Port
Manometer Port
Quick Connection
Quick Connection
Pressure Measurement Port
Pressure Measurement Port
G1/4"
G1/4"
Material
Material
Composite-PA66 GF30
Composite-PA66 GF30
* Optional
