ARC05
ARC05
ARC05
Hydraulic Groups
Horizontal Hydraulic Groups for Wall Hung Boilers
Horizontal Hydraulic Groups for Wall Hung Boilers
Pressure CH
Pressure CH
0 Bar to 3 Bar
0 Bar to 3 Bar
Pressure DHW
Pressure DHW
0,2 Bar to 10 Bar
0,2 Bar to 10 Bar
Flow Rate DHW
Flow Rate DHW
2-20 l/min
2-20 l/min
Pressure Relief Valve
Pressure Relief Valve
Brass 3 Bar
Brass 3 Bar
/
/
*Composite 3 Bar
*Composite 3 Bar
*Composite 3 Bar
Flow Restrictor
Flow Restrictor
-
-
/
/
*6 to 20 l/min
*6 to 20 l/min
*6 to 20 l/min
Filling System
Filling System
Manuel Tap 63mm
Manuel Tap 63mm
/
/
*37mm - 63 mm
*37mm - 63 mm
*37mm - 63 mm
Automatic Bypass
Automatic Bypass
Through PHE (380±30 mBar)
Through PHE (380±30 mBar)
Flow Detection
Flow Detection
Hall Effect Sensor
Hall Effect Sensor
Electric Connections
Electric Connections
Rast 2,5
Rast 2,5
Three Way Valve
Three Way Valve
ON-OFF Motor
ON-OFF Motor
NTC Port
NTC Port
G1/8"
G1/8"
Manometer Port
Manometer Port
M14x1
M14x1
Pressure Measurement Port
Pressure Measurement Port
G1/4"
G1/4"
Material
Material
Brass- CuZn40Pb2(CW617N)
Brass- CuZn40Pb2(CW617N)
* Optional
