ARC03
ARC03
ARC03
Hydraulic Groups
Horizontal Hydraulic Groups for Wall Hung Boilers
Horizontal Hydraulic Groups for Wall Hung Boilers
Pressure CH
Pressure CH
0 bar to 3 bar
0 bar to 3 bar
Pressure DHW
Pressure DHW
0,2 bar to 10 bar
0,2 bar to 10 bar
Flow Rate DHW
Flow Rate DHW
2-20 l/min
2-20 l/min
Pressure Relief Valve
Pressure Relief Valve
Brass 3 Bar
Brass 3 Bar
/
/
*Composite 3 Bar
*Composite 3 Bar
*Composite 3 Bar
Flow Restrictor
Flow Restrictor
-
-
/
/
*6 - 20 l/min
*6 - 20 l/min
*6 - 20 l/min
Filling System
Filling System
Manuel Tap 63 mm
Manuel Tap 63 mm
/
/
*37mm - 63mm
*37mm - 63mm
*37mm - 63mm
Automatic Bypass
Automatic Bypass
Through PHE (380±30 mBar)
Through PHE (380±30 mBar)
Flow Detection
Flow Detection
Hall effect sensor
Hall effect sensor
Electric Connections
Electric Connections
Rast 2,5
Rast 2,5
Three Way Valve
Three Way Valve
ON-OFF Motor
ON-OFF Motor
NTC Port
NTC Port
G1/8"
G1/8"
Manometer Port
Manometer Port
M14x1
M14x1
Pressure Measurement Port
Pressure Measurement Port
G1/4"
G1/4"
Material
Material
Brass - CuZn40Pb2 (CW617N)
Brass - CuZn40Pb2 (CW617N)
* Optional
